POWER FORCE YSS DTG Hybrid Low Down Rear Shock 285mm PCX (JF28 JF56 KF12 KF18) (White Spring)

DTG nitrogen gas and oil twin tube system Spring color: White Compatible models PCX JF28 (2010-2013), PCX JF56 (2014-2017 LED headlight model), PCX150 KF12 (2012-2013) ), PCX150 KF18 (2014-2017 LED headlight model) Not compatible with 2018 model and later (JF81/JF84/KF30). Installation length 285mm. (Original is 310mm to 315mm)

■Product name YSS DTG gas hybrid rear shock 285mm PCX PCX150 ■Manufacturer name YSS ■Manufacturer part number Free length 285mm White spring (PF-YSS-002 TB220-285T-01-82P-X) ■Compatible models PCX JF28 (2010-2013 ) PCX JF56 (2014-2017 LED headlight model) PCX150 KF12 (2012-2013) PCX150 KF18 (2014-2017 LED headlight model) **2018 model and later (JF81/JF84/KF30) does not fit. ■Product details DTG nitrogen gas and oil twin tube system Free length,.285mm Mounting part dimensions Upper side: Φ10x21 (mm), Lower side: Inner width 20xM8 (mm) Spring preload adjustment function ■Accessories - Rear shock body left and right 1 set - Preload adjustment tool ■Reference genuine rear shock length PCX125(JF28/JF56) …310mm PCX150(KF12/KF18) …310mm PCX125(JF81) …350mm PCX150(KF30) …350mm PCX125(JK05) …365mm PCX125 eHEV (JK06) …365mm PCX160(KF47) …365mm


Manufacturer: ‎YSS
Brand: ‎POWER FORCE
Model name: ‎PCX(JF28 JF56) PCX150(KF12 KF18) 2018 model year and later (JF81 /JF84/KF30).
Manufacturer reference: TB220-285T-01
Position: ‎Back
Color: ‎White Spring
Certification: ‎Only for initial defects
