Panasonic Earth Leakage Breaker BJW Type Motor Protection 125AF 3P3E 100A Sensitivity Current Switching BJW31009K
Panasonic Earth Leakage Breaker BJW Type Motor Protection 125AF 3P3E 100A Sensitivity Current Switching BJW31009K
Regular price
$228.00 USD
Regular price
Sale price
$228.00 USD
Unit price
/
per
Shipping calculated at checkout.
Condition: New
Couldn't load pickup availability
*If you are using a high-efficiency motor (because the starting current of the motor varies depending on the manufacturer), the breaker may operate when the motor starts, making it unusable. Be sure to check the starting characteristics of the motor with the motor manufacturer before use.
●*Reverse connection possible. (However, 150AF cannot be connected in reverse)
●*Please select the wire size that matches the rated current value.
●*Please remove the wires when measuring the insulation resistance between the lines.
●JIS agreement type ●Combined with motor protection ●Frame/model name: 125AF (BJW-125) ●Number of poles: 3P3E ●Sensitivity current: 100/200/500mA switching ●Rating: 100A 22kW ●Phase wire system: 3φ3W, 1φ3W ●Rated voltage/breaking capacity (sym): 25kA for both AC100-200V ●Operating time: Within 0.1 seconds ●Earth leakage display method: Mechanical button ●Terminal specifications: Compatible crimp terminal for crimp terminals (manufactured by Nichifu) 38-8S (included) )●Tightening torque: 5.5 to 7.0N・m●Included terminal cover: BCW31008125●Operable voltage range of earth leakage sensor: 80 to 242V (Earth leakage due to voltage fluctuations that occur when used at rated voltage) This is the voltage range in which the sensor operates normally. Please use the breaker at the rated voltage.) *If you are using a high-efficiency motor, the breaker may not operate when the motor starts (because the starting current of the motor varies depending on the manufacturer). , may not be available. Be sure to check the starting characteristics of the motor with the motor manufacturer before use. ●※Reverse connection possible. (However, 150AF cannot be connected in reverse) *Please select the wire size that matches the rated current value. ●*Remove the wires before measuring the insulation resistance between the wires. ●*When using 3P with 1φ3W, connect the neutral wire to the middle pole. In this case, open phase protection for the neutral wire cannot be performed. ●*Compatible with lightning surges and harmonics (inverters, etc.). For frequency control circuits such as inverters, be sure to install it on the primary side of the inverter. ●*Cannot be used for motor protection in frequency control circuits (inverters, etc.). Please install it on the primary side of the frequency control circuit to protect the wiring. ●*Please use the product that also serves as motor protection according to the motor rated current. ●*Please install the electromagnetic type with overcurrent tripping method within ±10° to the vertical plane (125AF). ●*If you need the back type (B) or flush-mounted type (FP), please use the BKW type or BKW-M type. ●※DIN rail cannot be installed.
Manufacturer: Panasonic
Part number: BJW31009K
Item weight: 1 Kilograms
Product size: 12.6 x 7.8 x 7.5 cm; 1 kg
Color: No
Style: 125 type 3P3E 100A 100/200/500mA
Voltage: 200 Volts
Accessories: No
Battery usage: No
Product Dimensions (Length x Width x Height): 12.6 x 7.8 x 7.5 cm
●*Reverse connection possible. (However, 150AF cannot be connected in reverse)
●*Please select the wire size that matches the rated current value.
●*Please remove the wires when measuring the insulation resistance between the lines.
●JIS agreement type ●Combined with motor protection ●Frame/model name: 125AF (BJW-125) ●Number of poles: 3P3E ●Sensitivity current: 100/200/500mA switching ●Rating: 100A 22kW ●Phase wire system: 3φ3W, 1φ3W ●Rated voltage/breaking capacity (sym): 25kA for both AC100-200V ●Operating time: Within 0.1 seconds ●Earth leakage display method: Mechanical button ●Terminal specifications: Compatible crimp terminal for crimp terminals (manufactured by Nichifu) 38-8S (included) )●Tightening torque: 5.5 to 7.0N・m●Included terminal cover: BCW31008125●Operable voltage range of earth leakage sensor: 80 to 242V (Earth leakage due to voltage fluctuations that occur when used at rated voltage) This is the voltage range in which the sensor operates normally. Please use the breaker at the rated voltage.) *If you are using a high-efficiency motor, the breaker may not operate when the motor starts (because the starting current of the motor varies depending on the manufacturer). , may not be available. Be sure to check the starting characteristics of the motor with the motor manufacturer before use. ●※Reverse connection possible. (However, 150AF cannot be connected in reverse) *Please select the wire size that matches the rated current value. ●*Remove the wires before measuring the insulation resistance between the wires. ●*When using 3P with 1φ3W, connect the neutral wire to the middle pole. In this case, open phase protection for the neutral wire cannot be performed. ●*Compatible with lightning surges and harmonics (inverters, etc.). For frequency control circuits such as inverters, be sure to install it on the primary side of the inverter. ●*Cannot be used for motor protection in frequency control circuits (inverters, etc.). Please install it on the primary side of the frequency control circuit to protect the wiring. ●*Please use the product that also serves as motor protection according to the motor rated current. ●*Please install the electromagnetic type with overcurrent tripping method within ±10° to the vertical plane (125AF). ●*If you need the back type (B) or flush-mounted type (FP), please use the BKW type or BKW-M type. ●※DIN rail cannot be installed.
