MAD COMPONENTS M9C12 IPE Black V3.0 100KV Brushless Motor for Multirotor Quadcopter Drone RC Hobby Rig

Professional aerial photography, surveying, mapping, exploration and other long flight tasks, 6S-12S voltage. Built-in fan design provides faster air flow and faster heat dissipation. Unique stator design, 36N42P configuration. Provides IP35 dustproof, waterproof protection, better security guarantee. With magnetic flux density and simulation of magnetic envelope, the motor is low energy consumption and high efficiency. Durable EZO imported bearings, more stable rotation, more resistant, and high performance arc magnets, the performance is improved by 5%.

MAD M9 C12 High Efficiency Drone Brushless Motor for Quadcopter Hexacopter, Octopus, RC Aircraft The M9 C12 INDUSTRY PRO EDITION UAV motor is designed to achieve waterproof and dustproof IP35 degree protection. Propeller mounting hole design and compatibility to setup installation. High performance, low power consumption in high voltage applications. Specification Model MAD M9 C12. RPM/V 90KV. Max current 30.4A. Rated voltage 48V. No load current 1.25A/20V. Internal resistance 74mΩ. Max thrust 10492g Max watts 1461W. Max torque 4.57N*m Centrifugal heat dissipation possible. Protection grade IP35. Propeller mounting holes M3 Ø20*4. Motor mounting holes M3 Ø30/50*4 M4 Ø32*4 Recommended propeller 28ft~32ft. ESC AMPX 80A recommended. Weight/rotor 28ft/3.5kg, 29ft/4kg, 30/4.5kg, 32ft/5.5kg. Weight/motor 29ft/quadcopter 16kg, hexacopter 24kg, octocopter 32kg.


Manufacturer: ‎jiangxi MAD motor components co.LTD
Part Number: ‎0101DJ0255
Item Weight: ‎898 g
Package Dimensions: ‎20.19 x 20.09 x 7.19 cm; 898 g
Voltage: ‎48 Volts
Horsepower: ‎1461 Watts
Battery Use: ‎No
