Auto Parts Tokyo
Ichinen TASCO TA456MS Safety non-contact phase detector
Ichinen TASCO TA456MS Safety non-contact phase detector
Regular price
$194.00 USD
Regular price
Sale price
$194.00 USD
Unit price
/
per
Shipping calculated at checkout.
Condition: New
Couldn't load pickup availability
Dimensions: W60 x D36 x H112mm/Weight: Approx. 380g Batteries used: 4 AA alkaline batteries (LR6) (auto power off for about 10 minutes) Measurement principle: Static induction method/Measurement frequency range: 45~66Hz Measurement voltage range: Three-phase AC70~1000V (sine wave, continuous) Measured conductor diameter: Insulated wire with finished outer diameter φ2.4~30mm (conductor nominal area 2~325mm2) Battery voltage warning: (When battery is exhausted) Power LED flashes Operating temperature and humidity Range: -10~+50℃, 80% (non-condensing)
Measurement cord: 0.7m (R: red S: white T: blue) Accessories: Carrying case, AA alkaline batteries (LR6) x 4, instruction manual Increase number of items displayed
Advantages: Safely measures wires from 2mm2 to 325mm2 (5) from above the wire coating. Check phase order, open phase, and ground phase using LED and buzzer. Comes with a magnet that can be installed inside the switchboard. Wide measurement voltage range from 3-phase AC70V to 1000V. The LED light-up function allows you to see clearly even in daylight. International safety standard IEC601010-1 Finished outer diameter: φ2.4~30mm Safely perform phase detection by rotating the phase detection arrow and buzzer! ! Nominal cross-sectional area of conductor: Compatible with 2~235mm2 electric wire
Brand: Ichinen TASCO
Product model number: TA456MS
Package size: 15 x 10 x 5 cm; 400 g
Name on nameplate: Compact
Power source: Battery powered
Product weight : 400g
Advantages: Safely measures wires from 2mm2 to 325mm2 (5) from above the wire coating. Check phase order, open phase, and ground phase using LED and buzzer. Comes with a magnet that can be installed inside the switchboard. Wide measurement voltage range from 3-phase AC70V to 1000V. The LED light-up function allows you to see clearly even in daylight. International safety standard IEC601010-1 Finished outer diameter: φ2.4~30mm Safely perform phase detection by rotating the phase detection arrow and buzzer! ! Nominal cross-sectional area of conductor: Compatible with 2~235mm2 electric wire
Brand: Ichinen TASCO
Product model number: TA456MS
Package size: 15 x 10 x 5 cm; 400 g
Name on nameplate: Compact
Power source: Battery powered
Product weight : 400g
