Auto Parts Tokyo

Gcraft Oil Catch Tank Type 6 Monkey/Gorilla 37022

Gcraft Oil Catch Tank Type 6 Monkey/Gorilla 37022

Regular price $140.00 USD
Regular price Sale price $140.00 USD
Sale Sold out
Tax included. Shipping calculated at checkout.

Condition: New

Material: Aluminum

This is a catch tank that is attached using the fender fixation of the frame. It can fill the gap between the rear tire and the frame. Ideal for those who cannot install it next to the tank using an up-muffler. Can be installed simultaneously with our back step. [Installation Guide] In the case of 8-inch 120/70/8 banana tires, it can be installed on a triple square mini swing arm that is +4 cm long. (Rear shock 285mm) For 10 inch 130/70/10 Michelin S1, it can be installed on +10 cm long triple square swing arm. (Rear shock 305mm) Drain bolt thread size M20-P2.5 Hose outlet diameter: Φ10 (2 pieces), Φ8 (1 piece) From frame mounting surface to outside of tank 110mm (including 10mm mounting collar) Catch tank size: Diameter 80mm, Width 114mm [Caution] It cannot be installed simultaneously with products that use the frame's fender mounting holes, such as back fender stays, Perafen, or our rear fender. Cannot be installed on the GC-019 frame (because the mounting pitch is different) For twin shock swing arm only [Material] A6063 material [Surface treatment] Buffed


Manufacturer: Gcraft
>Brand: Gcraft
Model name: Aluminum
Package size: 18.8 x 16 x 15.9 cm; 487.99 g
Product model number: 37022
Certification: None . Available on a case-by-case basis.
Product weight: ‎488 g
