Panduit Domestic Genuine Copper Compression Terminal 1 Hole Flex Wire Compatible Lug AWG8 Mounting Hole 6.9mm 50 Pieces LCAX8-14-L

Can be used for general stranded wires and flex wires (classes: G, H, I, K, M, diesel locomotives). The insertion opening is firmly chamfered to prevent the strands from fraying when inserting the wires. The barrel is color coded according to the applicable wire size and is engraved with the compression die number used. You can check whether the wire is completely inserted through the wire confirmation hole in the barrel. Tin plated to prevent corrosion. UL Listed and CSA certified product. However, this applies only when compressed using a Panduit compression tool and compression die in an environment of 90°C or lower and 35KV or lower. ABS certified product

Material: Tin-plated copper Product type: Tin-plated copper Compression terminal Barrel: Standard barrel with hole for confirming wire insertion Barrel angle: Straight Mounting plate: Standard width type Wire insertion port: Standard type Flex Wire size (Class G, H, I): AWG8 Flex wire size (Class G, H, I, K, M): AWG8 Flex wire size (Class K, M): AWG8 Stranded wire wire size: AWG8 Flex wire size (diesel locomotive): AWG8 Mounting hole size In. mm):1/4 (6.4)Barrel length In. (mm):0.42 (10.7)Length In (mm):1.2 (30.5)Mounting plate thickness In. (mm):0.07 (1.8)Mounting plate width In (mm): 0.48 (12.2) Identification color: Red Die number: P21 Wire strip length In. (mm): 1/2 (12.7) Burndy Die number: 49T&B Die number: 21 ABS certified product CSA certification: C22.2 No. 65-13 Tin plating: Conforms to ASTM B545-97, Class C: 320µ in (8µ m) UL, CSA certified Operating temperature: 90°C or less UL, CSA certified Rated voltage: 35kV or less UL Listed: 486A-486B, File No. E52164 Technical Information: Check with cable manufacturer when using in applications above 2000V. Flex wire size (class: G, H, I, K, M, diesel locomotive): AWG8 Barrel angle: Straight Barrel shape: Standard mounting hole size: 6.9mm RoHS compliant product


Manufacturer: ‎ Panduit Corporation
Part number: LCAX8-14-L
Product weight: 4.54 g
Product size: 10 x 6 x 9 cm; 4.54 g
Size: ‎ 1/4-Inch Stud Hole
Color: ‎—
Style: ‎#8 AWG Wire
Material: ‎Tin-plated Copper
Thickness: ‎0.07 inch
Measurement System: ‎inch
br>Chlorine removal rate: CE
Accessories: None
Batteries included: No
Batteries used: No
Product dimensions (Length x Width x Height): 10 x 6 x 9cm
