Tamiya 1/10 Electric RC Car Series No.647 M-07 CONCEPT Chassis Kit On-Road 58647

[A compact chassis kit that pursues maneuverability and driving pleasure] The M-07 CONCEPT is a compact chassis that pursues the light running performance and maneuverability that can only be achieved with front-wheel drive, and is also particular about maintainability. The main frame is a monocoque type that combines a resin lower deck and an upper frame to ensure rigidity. What's more, when replacing the differential gear, the number of disassembly points around the suspension is minimized, and maintenance is easy as it can be accessed from the bottom. Suspension is 4 independent double wishbone wheels equipped with CVA oil dampers. It is a specially designed product with a longer arm and linkage, and is also characterized by a wide range of settings. Furthermore, we have achieved a loss-free drive system by using full bearing specifications, oil-filled gear differentials, and universal shafts. In addition, two types of wheelbase can be selected: 239mm and 225mm. I'm also looking forward to choosing and installing a body for the M chassis that is available in abundance. [Main equipment parts] ●Monocoque type frame with upper and lower split type ●Long suspension arm with wide setting width ●CVA oil damper ●Full bearing specification ●Oil-filled gear differential ●Universal shaft ●High torque servo saver [Basic specs] ●Chassis length 332mm ( (Including bumper) ●Chassis width 164mm ●Two types of wheelbase 239mm and 225mm can be selected ●Frame = monocoque type with upper and lower split ●Drive system = front midship motor, front wheel drive ●Differential gear = oil-filled gear differential ●Steering = 3 Split tie rod type ●Suspension: 4-wheel double wishbone ●Damper: CVA oil damper ●Gear ratio: 9 types from 7.22:1 to 4.81:1 (5.78:1 when using the 20T pinion included in the kit) ●Speed ​​controller: ESC specification ( (sold separately) [Required separately] ●Body for M chassis ●540 type motor ●Tires ●RC mechanism: EXPEC GT-I 2.4G (set for electric RC cars) ●Battery for running, charger ●Power source for transmitter *Body, motor, tires, RC mechanism, battery, etc. are not included in the kit.

A completely newly designed chassis that focuses on improving driving performance and ease of maintenance. The main chassis is divided into upper and lower parts, greatly improving maintainability. Improved differential and stabilizer adjustment. The suspension is also completely new. Optimized front-rear balance with long arms. Equipped with rear toe-in adjustment function as standard. The differential is an oil-filled differential gear. Greatly contributes to improving acceleration performance and cornering performance. CVA damper, universal drive shaft, and high torque servo saver are standard equipment. Full bearing specification. *RC mechanism, motor, battery, body, and tires are sold separately. Safety Warning Please drive in a wide and safe place such as a dedicated RC car circuit. Never run it on the road. Do not run in crowded areas, parks, or near small children. Do not run it in small spaces or indoors. Please do not run it in places where it may be a nuisance to others, such as schools, hospitals, or residences. Do not run at night or early in the morning. Do not use any other than specified charging equipment to charge the battery. The charger that can be used differs depending on the type and capacity of the battery. Using an unspecified charging device is extremely dangerous as it may generate heat, catch fire, or explode. Be sure to charge the battery in a place where you can see it and there is nothing nearby.
