Yoshitake Pressure Reducing Valve, For Apartment Housing, With Check Valve For Individual Water Supply, Outlet Pressure 0.05~0.25MPa, Screw Connection, Port Size 15A, Main Unit CAC, Maximum Temperature 60℃, Model GD-15C 15A
Yoshitake Pressure Reducing Valve, For Apartment Housing, With Check Valve For Individual Water Supply, Outlet Pressure 0.05~0.25MPa, Screw Connection, Port Size 15A, Main Unit CAC, Maximum Temperature 60℃, Model GD-15C 15A
Regular price
$129.00 USD
Regular price
Sale price
$129.00 USD
Unit price
/
per
Shipping calculated at checkout.
Condition: New
Couldn't load pickup availability
Country of manufacture: Japan Applicable fluid: Tap water Primary pressure range: 0.1 to 1.0 MPa Secondary pressure range: 0.05 to 0.25 MPa (standard setting 0.2 MPa) Maximum temperature: 60°C For housing complexes Main body: CAC valve body :NBR Valve seat: CAC Diaphragm: NBR Water supply law standard compliant product
The GD-15 type pressure reducing valve is a product that realizes low-noise water supply as a pressure reducing valve for individual water supply in apartment complexes, etc. It can maintain extremely stable outlet pressure against fluctuations in water supply pressure, and has a built-in strainer and is designed to be small and lightweight, making piping easy to handle. We have eliminated the noise from the pressure reducing valve itself, so you can feel safe even when supplying water late at night. The water supply pressure is already adjusted to the standard setting pressure, so there is no need to adjust the pressure on site. The valve structure uses a pressure balance structure, so the secondary pressure is always kept constant without being affected by the primary pressure. Since it has a built-in strainer, if there is any dirt or sand mixed in, it will be collected to prevent it from getting caught in the valve part or flowing out to the secondary side. The strainer cap can be removed without using tools. Additionally, since the strainer and strainer cap are integrated, no strainer remains inside the valve box, making maintenance and inspection easy. The sealed structure prevents fluid from leaking outside even if the diaphragm is damaged. The piping installation direction (horizontal or vertical) is arbitrary. GD-15C has a built-in check mechanism to prevent backflow to the water mains.
Brand: Yoshitake
Product model number: GD-15C 15A
Package size: 18 x 14.8 x 11.2 cm; 1.04 kg
Material: CAC, NBR
br>Product weight: 1.04 Kilograms
The GD-15 type pressure reducing valve is a product that realizes low-noise water supply as a pressure reducing valve for individual water supply in apartment complexes, etc. It can maintain extremely stable outlet pressure against fluctuations in water supply pressure, and has a built-in strainer and is designed to be small and lightweight, making piping easy to handle. We have eliminated the noise from the pressure reducing valve itself, so you can feel safe even when supplying water late at night. The water supply pressure is already adjusted to the standard setting pressure, so there is no need to adjust the pressure on site. The valve structure uses a pressure balance structure, so the secondary pressure is always kept constant without being affected by the primary pressure. Since it has a built-in strainer, if there is any dirt or sand mixed in, it will be collected to prevent it from getting caught in the valve part or flowing out to the secondary side. The strainer cap can be removed without using tools. Additionally, since the strainer and strainer cap are integrated, no strainer remains inside the valve box, making maintenance and inspection easy. The sealed structure prevents fluid from leaking outside even if the diaphragm is damaged. The piping installation direction (horizontal or vertical) is arbitrary. GD-15C has a built-in check mechanism to prevent backflow to the water mains.
Brand: Yoshitake
Product model number: GD-15C 15A
Package size: 18 x 14.8 x 11.2 cm; 1.04 kg
Material: CAC, NBR
br>Product weight: 1.04 Kilograms
