Panasonic Earth Leakage Breaker BJW Type with O.C 50AF 3P3E 40A Sensitivity 100mA BJW3404

*If you are using a high-efficiency motor (because the starting current of the motor varies depending on the manufacturer), the breaker may operate when the motor is started, making it unusable. Be sure to check the starting characteristics of the motor with the motor manufacturer before use.
●*Reverse connection possible.
●*Please select the wire size that matches the rated current value.
●*Please remove the wires when measuring the insulation resistance between the lines.

●Quantity (units): 1●Frame/model name: 50AF (BJW-50)●Number of poles: 3P3E●Sensitivity current: 100mA●Rated current: 40A●Phase wire type: 3φ3W, 1φ3W●Rated voltage/interruption Capacity: AC100-200V dual use/2.5kA ●Operating time: within 0.1 seconds ●Earth leakage display method: Mechanical button ●Tripping method: Electromagnetic ●Combined with motor protection ●With O.C. ●With opening/closing flap small terminal cover (BCW30308125)● Earth leakage sensor operating voltage range: 80 to 242V (*This is the voltage range in which the earth leakage sensor operates normally against voltage fluctuations that occur when used at the rated voltage. Please use the breaker at the rated voltage.)


Manufacturer: ‎Panasonic
Part number: ‎BJW3404
Product weight: 45 g
Product size: ‎10.6 x 7 x 6.8 cm; 45 g
Style: ‎50 type 3P3E 40A 100mA
Voltage: ‎200 volts
Accessories: ‎Instruction manual
Battery usage: ‎No
Product dimensions (Length x Width x Height): ‎ 10.6 x 7 x 6.8cm
