OMRON Limit Switch 2 Circuits WL-N Type WLNJ-N
OMRON Limit Switch 2 Circuits WL-N Type WLNJ-N
Regular price
$63.00 USD
Regular price
Sale price
$63.00 USD
Unit price
/
per
Shipping calculated at checkout.
Condition: New
Couldn't load pickup availability
Series: WL-N Features: 2-circuit limit switch Actuator type: Coil spring (spring diameter φ6.5) Movement until operation (PT): 20 ± 10 mm Inrush current normally closed: Max. 30 A (Max. 15 A) Inrush current normally open: 20 A maximum (10 A max.) Minimum applicable load: 5 VDC 1 mA resistive load P level Protection structure: IP67 Allowable operating speed: 1 mm to 1 m/s (for WLCA2-N) Rated frequency: 50/60 Hz Insulation resistance: 100MΩ or more (at 500V DC) Ambient operating temperature: -10~+80℃ (no freezing)
A wide variety of general types: rotary lever type, plunger type, flexible rod type, fork lock lever type head shapes, and a variety of actuators, allowing you to select a product according to the workpiece shape and movement. 6 types of environmental resistant types are available. Highly sealed, highly sealed, heat resistant, cold resistant, corrosion resistant, and weather resistant types are available. Can be selected according to the site environment. Stainless steel and resin materials are used to prevent spatter adhesion, making it ideal for welding sites. Reduces troubles caused by zinc powder generated during welding. Long-life type Suitable for frequent use, the long-life type head has improved wear resistance and sliding properties, achieving mechanical durability of over 30 million cycles. Common Features: The contact part has 2 circuits double-break and 2 circuits double-break to ensure the circuit is cut off. Standard type / Holding type (WL-N) WL-N / WL Features 11 High sensitivity type / High precision type (WL) WL-N / WL Features 12 IP67 protection structure Operation display type neon lamp for easy daily inspection or Operating status is indicated by LED. Easy check and maintenance at startup. We have a lineup of sensor I/O connector types that match wiring specifications, direct connector types, and pre-wired connector types. Easily replace limit switches. A wide variety of 2-circuit limit switches that can be selected according to the usage environment and application.
Manufacturer: OMRON
Part number: WLNJ-N
Product weight: 250 g
Package size: 22.1 x 14.4 x 5.7 cm; 250 g
Style: Actuator type: Coil spring (spring diameter φ6.5) Movement to operation (PT): 20±10mm
Pattern: WLNJ-N
Switch style: Limit Switch
Uses batteries: No
A wide variety of general types: rotary lever type, plunger type, flexible rod type, fork lock lever type head shapes, and a variety of actuators, allowing you to select a product according to the workpiece shape and movement. 6 types of environmental resistant types are available. Highly sealed, highly sealed, heat resistant, cold resistant, corrosion resistant, and weather resistant types are available. Can be selected according to the site environment. Stainless steel and resin materials are used to prevent spatter adhesion, making it ideal for welding sites. Reduces troubles caused by zinc powder generated during welding. Long-life type Suitable for frequent use, the long-life type head has improved wear resistance and sliding properties, achieving mechanical durability of over 30 million cycles. Common Features: The contact part has 2 circuits double-break and 2 circuits double-break to ensure the circuit is cut off. Standard type / Holding type (WL-N) WL-N / WL Features 11 High sensitivity type / High precision type (WL) WL-N / WL Features 12 IP67 protection structure Operation display type neon lamp for easy daily inspection or Operating status is indicated by LED. Easy check and maintenance at startup. We have a lineup of sensor I/O connector types that match wiring specifications, direct connector types, and pre-wired connector types. Easily replace limit switches. A wide variety of 2-circuit limit switches that can be selected according to the usage environment and application.
Manufacturer: OMRON
Part number: WLNJ-N
Product weight: 250 g
Package size: 22.1 x 14.4 x 5.7 cm; 250 g
Style: Actuator type: Coil spring (spring diameter φ6.5) Movement to operation (PT): 20±10mm
Pattern: WLNJ-N
Switch style: Limit Switch
Uses batteries: No
