Auto Parts Tokyo
ELECOM HDMI Extender VEX-HD1001S
ELECOM HDMI Extender VEX-HD1001S
Regular price
$597.00 USD
Regular price
Sale price
$597.00 USD
Unit price
/
per
Shipping calculated at checkout.
Condition: New
Couldn't load pickup availability
This is an HDMI extender that complies with HDBaseT ClassA and can extend HDMI signals up to 100m with a single LAN cable. High-quality HDMI image signals and high-quality audio signals can be transmitted over long distances at the same time. Since it can be extended using a LAN cable, it is easy to handle and has excellent cost performance. *LAN cable is not included. Please purchase separately. Compatible with resolution 4KUHD (30Hz). It supports HDMI Ver.1.3b and also supports Deep Color and DolbyTrueHD. This product supports HDCP (High-bandwidth Digital Content Protection). *The display side must also support HDCP. Adopts EDID pass-through method.
Equipped with an anti-jamming function that detects and automatically removes noise. It is also possible to connect to multiple units by using a distributor etc. Two rack mount plates are included for installation. Increase number of displayed items
[Specifications] ■Compatible models (video output devices): Computers, AV devices, etc. equipped with HDMI (type A) terminals ■Compatible models (displays): Displays, projectors, etc. equipped with HDMI input terminals ■Maximum number of connectable devices: Video output Device: 1 unit / Video display device: 1 unit ■Interface (transmitting side): Input terminal: HDMI (type A) x 1 / Line output port: RJ45 x 1 ■Interface (receiving side): Output terminal: HDMI (type A) ) x 1/Line input port: RJ45 x 1 Maximum extension distance: When using Category 6a/7 cable: 100m (4K and 1080p), When using Category 5e/6 cable: 100m (1080p) *Supported 4K resolutions are 3840×2160@30Hz(4:4:4), 3840×2160@60Hz(4:2:0), 4096×2160@30Hz(4:4:4), 4096×2160@60Hz(4:2:0 )is. ■Maximum resolution: When using Category 6a/7 cable: 4K (100m), When using Category 5e/6 cable: 4K (70m) *Supported 4K resolutions are 3840 x 2160@30Hz (4:4:4), 3840 ×2160@60Hz(4:2:0), 4096×2160@30Hz(4:4:4), 4096×2160@60Hz(4:2:0). ■Maximum data transfer rate: 10.2Gbps■Maximum pixel clock: 340MHz■Compliant standards: HDMI (3D, DeepColor, 4K), HDCP, CEC, Dolby True HD, HD Master Audio■Certification: HDBaseT certified ■Case material: Metal■ Body size: 142mm x 30mm x 103mm ■Weight: Approximately 430g ■Power consumption: Transmitter: 1.9W/Receiver: 4.5W ■AC adapter power specifications: Input: AC100V~240V, 50/60Hz, Output: DC5.3V/ 2.4A ■Operating environment temperature: 0~50℃ ■Storage temperature/humidity: -20~50℃/0~80%RH (no condensation) ■Others: Equipped with anti-jamming function, EDID pass-through method adopted ■Accessories: Power adapter : 2 pieces Installation plate: 2 pieces Instruction manual (including warranty card): 1 piece ■Warranty period: 1 year [Description] ■Compliant with HDBaseT ClassA, HDMI signal can be extended up to 100m with one LAN cable It's an extender. ■High-quality HDMI image signals and high-quality audio signals can be transmitted over long distances. ■Since it can be extended using a LAN cable, it is easy to handle and has excellent cost performance. *LAN cable is not included. Please purchase separately. ■Supports resolution 4KUHD (30Hz). ■Compatible with HDMI Ver.1.3b and also supports Deep Color and DolbyTrueHD. ■This product supports HDCP (High-bandwidth Digital Content Protection). *The display side must also support HDCP. ■Uses EDID pass-through method. ■Equipped with an anti-jamming function that detects and automatically removes noise. ■Connection to multiple units is also possible by using a distributor etc. ■Two rack mount plates for installation are included. ■Products that meet one or more of our company's environmental certification standards and display the "THINK ECOLOGY" mark. ■In an effort to protect the environment, this product reduces the weight of plastic in its packaging by more than 20% compared to internal standard products. ■In an effort to protect the environment, this product is packaged only in paper, cardboard, and plastic bags. [Inquiries regarding products] ELECOM General Information Center TEL. 0570-084-465FAX. 0570-050-012 Reception hours / 10:00~19:00 Open all year round
Connector male/female: Female-Female
Compatible models: Projector
Color: Black
Shape: Round
Battery included: No
Battery usage: No
Brand name: ELECOM
Manufacturer: ELECOM
Product model number: VEX-HD1001S
Others Features: High-quality HDMI image signal with one LAN cable This enables high-quality audio signals to be transmitted over long distances. HDBaseT(R) certified HDMI extender that can extend HDMI signals up to 100m.
Cable shape: Ethernet
Packing size: 29 x 18.8 x 10.2 cm; 1.48 kg
[Specifications] ■Compatible models (video output devices): Computers, AV devices, etc. equipped with HDMI (type A) terminals ■Compatible models (displays): Displays, projectors, etc. equipped with HDMI input terminals ■Maximum number of connectable devices: Video output Device: 1 unit / Video display device: 1 unit ■Interface (transmitting side): Input terminal: HDMI (type A) x 1 / Line output port: RJ45 x 1 ■Interface (receiving side): Output terminal: HDMI (type A) ) x 1/Line input port: RJ45 x 1 Maximum extension distance: When using Category 6a/7 cable: 100m (4K and 1080p), When using Category 5e/6 cable: 100m (1080p) *Supported 4K resolutions are 3840×2160@30Hz(4:4:4), 3840×2160@60Hz(4:2:0), 4096×2160@30Hz(4:4:4), 4096×2160@60Hz(4:2:0 )is. ■Maximum resolution: When using Category 6a/7 cable: 4K (100m), When using Category 5e/6 cable: 4K (70m) *Supported 4K resolutions are 3840 x 2160@30Hz (4:4:4), 3840 ×2160@60Hz(4:2:0), 4096×2160@30Hz(4:4:4), 4096×2160@60Hz(4:2:0). ■Maximum data transfer rate: 10.2Gbps■Maximum pixel clock: 340MHz■Compliant standards: HDMI (3D, DeepColor, 4K), HDCP, CEC, Dolby True HD, HD Master Audio■Certification: HDBaseT certified ■Case material: Metal■ Body size: 142mm x 30mm x 103mm ■Weight: Approximately 430g ■Power consumption: Transmitter: 1.9W/Receiver: 4.5W ■AC adapter power specifications: Input: AC100V~240V, 50/60Hz, Output: DC5.3V/ 2.4A ■Operating environment temperature: 0~50℃ ■Storage temperature/humidity: -20~50℃/0~80%RH (no condensation) ■Others: Equipped with anti-jamming function, EDID pass-through method adopted ■Accessories: Power adapter : 2 pieces Installation plate: 2 pieces Instruction manual (including warranty card): 1 piece ■Warranty period: 1 year [Description] ■Compliant with HDBaseT ClassA, HDMI signal can be extended up to 100m with one LAN cable It's an extender. ■High-quality HDMI image signals and high-quality audio signals can be transmitted over long distances. ■Since it can be extended using a LAN cable, it is easy to handle and has excellent cost performance. *LAN cable is not included. Please purchase separately. ■Supports resolution 4KUHD (30Hz). ■Compatible with HDMI Ver.1.3b and also supports Deep Color and DolbyTrueHD. ■This product supports HDCP (High-bandwidth Digital Content Protection). *The display side must also support HDCP. ■Uses EDID pass-through method. ■Equipped with an anti-jamming function that detects and automatically removes noise. ■Connection to multiple units is also possible by using a distributor etc. ■Two rack mount plates for installation are included. ■Products that meet one or more of our company's environmental certification standards and display the "THINK ECOLOGY" mark. ■In an effort to protect the environment, this product reduces the weight of plastic in its packaging by more than 20% compared to internal standard products. ■In an effort to protect the environment, this product is packaged only in paper, cardboard, and plastic bags. [Inquiries regarding products] ELECOM General Information Center TEL. 0570-084-465FAX. 0570-050-012 Reception hours / 10:00~19:00 Open all year round
Connector male/female: Female-Female
Compatible models: Projector
Color: Black
Shape: Round
Battery included: No
Battery usage: No
Brand name: ELECOM
Manufacturer: ELECOM
Product model number: VEX-HD1001S
Others Features: High-quality HDMI image signal with one LAN cable This enables high-quality audio signals to be transmitted over long distances. HDBaseT(R) certified HDMI extender that can extend HDMI signals up to 100m.
Cable shape: Ethernet
Packing size: 29 x 18.8 x 10.2 cm; 1.48 kg
